Stainless steel and copper distillers for essential oils and schnapps distilling

42 l stainless steel still with pressurized water bath, 2 columns, dephlegmator and high-performance cooling - Plus-(without, GH, IH)
TOP

42 liters of water still, 2 columns
Dephlegmator, high
performance counterflow cooling
Pot still or counterflow distillation selectable
Various firings

The DESTILLIERMEISTER JUMBO-Premium WD42 Plus XX with pressurized water bath is the youngest member of our distillery family, which is just as well suited for the production of high-quality aromatic fruit brandies as for the alcohol distillation of pure fruit pomace or from starch-containing products such as grain and potatoes. The system is operated in different modes. In the present plant, both rectifier columns are used and, in order to control the distillate withdrawal / reflux ratio, a controllable dephlegmator is used in the stainless steel helmet. The advantage over a pure column system, which has static parameters, is the controllability of flow and return, which makes the firing process more dynamic and variable. Each distiller can determine the optimum operating conditions for his plant. Only basic recommendations for the operation are given here. For pre- and post-run separation, settings adjusted to the respective task can be made. For trailers of classical DC distillation, the dephlegmator can also be easily switched off. The rectification plates can now be removed so that unimpeded heat exchange is possible even via the extension units. For firing smaller quantities, a 12 liter module can also be removed. The lower combustion chamber and the two expansion units can, unlike in previous models, be firmly closed before putting on the helmet, so that even with increasing aging of the seals, the connection between the individual modules remains tight and over the entire height (less consideration rising space ) can be filled. The relevant bubble space is now actually 42 liters and this is also relevant for Customs, which in previous cases, where the pots were not firmly connected and separated by the trays, used only the lower bladder (20.5 liters) .

The actual column and dephlegmator operation is used in countercurrent distillation. There are several variants of the DESTILLIERMEISTER JUMBO-Premium WD42 Plus XX

from EUR 2.499,00
incl. 19% tax excl. Shipping costs
DESTILLIERMEISTER JUMBO W42

DESTILLIERMEISTER JUNIOR-WD42

42 l stainless steel still with pressurized water bath, 2 columns, dephlegmator and high-performance cooling for the production of brandy

High Quality:

  • Solid thick-walled boiler for the water bath

  • with pressure measurement and safety valves,

  • made of 18/10 stainless steel with three-layered thermo bottom

Equipment and dimensions

  • Water bath boiler with safety system for the pressurized water bath: 25 liters

  • Mash-water boilers: 20.5 Litres,

  • 2 Columns / combustion-chamber extensions: 12 Litres,

  • Dephlegmator,

  • Inner Diameter 32 cm,

  • Total height approx. 170 cm.

  • Powerful counterflow cooler with 6 m jacket length. In this cooler, a thinner pipe (core) passes through a jacket pipe. Through the soul flows the distillate. Between soul and coat cooling water is passed in countercurrent. Due to the spiral-shaped water flow, the flow between soul and mantle is turbulent even at low flow velocities. This causes effective heat transfer from the distillate to the cooling water. Because of this and because of the comfortable length of the radiator, only moderate cooling water is needed.

EUR 2.199,00
incl. 19% tax excl. Shipping costs
DESTILLIERMEISTER JUMBO W42

DESTILLIERMEISTER JUNIOR-WD42

42 l stainless steel still with pressurized water bath, 2 columns, dephlegmator, high-performance cooling and 10,5 kW gas-cooker for the production of brandy

High Quality:

  • Solid thick-walled boiler for the water bath

  • with pressure measurement and safety valves,

  • made of 18/10 stainless steel with three-layered thermo bottom

Equipment and dimensions

  • Water bath boiler with safety system for the pressurized water bath: 25 liters

  • Mash-water boilers: 20.5 Litres,

  • 2 Columns / combustion-chamber extensions: 12 Litres,

  • Dephlegmator,

  • Inner Diameter 32 cm,

  • 10,5 kW gas-cooker with ignition protection

  • Total height approx. 170 cm.

  • Powerful counterflow cooler with 6 m jacket length. In this cooler, a thinner pipe (core) passes through a jacket pipe. Through the soul flows the distillate. Between soul and coat cooling water is passed in countercurrent. Due to the spiral-shaped water flow, the flow between soul and mantle is turbulent even at low flow velocities. This causes effective heat transfer from the distillate to the cooling water. Because of this and because of the comfortable length of the radiator, only moderate cooling water is needed.

EUR 2.199,00
incl. 19% tax excl. Shipping costs
DESTILLIERMEISTER JUMBO W42

DESTILLIERMEISTER JUNIOR-W42

42 l stainless steel still with pressurized water bath, 2 columns, high-performance cooling and 10,5 kW gas-cooker for the production of brandy

High Quality:

  • Solid thick-walled boiler for the water bath

  • with pressure measurement and safety valves,

  • made of 18/10 stainless steel with three-layered thermo bottom

Equipment and dimensions

  • Water bath boiler with safety system for the pressurized water bath: 25 liters

    The water bath system may only be operated in the fully closed state, that is, all the latches are closed.

  •  Mash-water boilers: 20.5 Litres,

  • 2 Columns / combustion-chamber extensions: 12 Litres,

  • Inner Diameter 32 cm,

  • Total height approx. 170 cm.

  • Powerful counterflow cooler with 3 m jacket length. In this cooler, a thinner pipe (core) passes through a jacket pipe. Through the soul flows the distillate. Between soul and coat cooling water is passed in countercurrent. Due to the spiral-shaped water flow, the flow between soul and mantle is turbulent even at low flow velocities. This causes effective heat transfer from the distillate to the cooling water. Because of this and because of the comfortable length of the radiator, only moderate cooling water is.

  • 10,5 kW gas-cooker with ignition protection

EUR 1.899,00
incl. 19% tax excl. Shipping costs
DESTILLIERMEISTER JUMBO W42

DESTILLIERMEISTER JUNIOR-W42

42 l Edelstahl Destille mit Druckwasserbad,  2 Kolonnen und Hochleistungskühlung zur Herstellung von Branntwein ohne Anbrennen der Maische

Hohe Qualität:

  • Solider dickwandiger Kessel für das Wasserbad mit Druckmessung und Sicherheitsventilen, aus 18/10 Edelstahl mit dreischichtigem Thermoboden.
  • Zum Wasserbadkessel passender Tauchkessel für die Maische.
  •  Sicher verschließbar mit Spannverschlüssen und Spannschlössern.
  •  Hygiene durch Edelstahl - keine Grünspangefahr wie bei Kupfer.

Ausstattung und Maße

  • Wasserbadkessel mit Sicherheitssystem für das Druckwasserbad: 25 Liter.
  •  Maische-Wasserbadkessel: 20,5 Liter,
  •  2 Kolonnen / Brennblasenerweiterungen: 12 Liter,
  •  Innen-Durchmesser: 32 cm,
  •  Gesamthöhe: ca. 170 cm.
  • Leistungsfähiger Gegenstromkühler mit 3 m Mantellänge. Bei diesem Kühler läuft ein dünneres Rohr (Seele) durch ein Mantelrohr. Durch die Seele fließt das Destillat. Zwischen Seele und Mantel wird im Gegenstrom Kühlwasser durchgeleitet. Aufgrund der spiralförmigen Wasserführung ist die Strömung zwischen Seele und Mantel bereits bei kleinen Strömungsgeschwindigkeiten turbulent. Das bewirkt eine effektive Wärmeübergabe vom Destillat ins Kühlwasser. Aufgrund dessen und wegen der komfortablen Länge des Kühlers wird nur mäßig Kühlwasser benötigt.

EUR 1.799,00
incl. 19% tax excl. Shipping costs
DESTILLIERMEISTER JUNIOR W23

DESTILLIERMEISTER JUNIOR-W23

23 l stainless steel still with pressurized water bath, 2 columns and high-performance cooling for the production of brandy

High Quality:

  • Solid thick-walled boiler for the water bath
  • with pressure measurement and safety valves,
  • made of 18/10 stainless steel with three-layered thermo bottom

Equipment and dimensions

  • Water bath boiler with safety system for the pressurized water bath: 16 liters

    The water bath system may only be operated in the fully closed state, that is, all the latches are closed.
  •  Mash-water boilers: 13,5 Litres,

  • 2 Columns / combustion-chamber extensions: 7 Litres,

  • Inner Diameter 28 cm,

  • Total height approx. 83 cm.

  • Powerful counterflow cooler with 1.6 m jacket length. In this cooler, a thinner pipe (core) passes through a jacket pipe. Through the soul flows the distillate. Between soul and coat cooling water is passed in countercurrent. Due to the spiral-shaped water flow, the flow between soul and mantle is turbulent even at low flow velocities. This causes effective heat transfer from the distillate to the cooling water. Because of this and because of the comfortable length of the radiator, only moderate cooling water is.

EUR 1.499,00
incl. 19% tax excl. Shipping costs
DESTILLIERMEISTER JUNIOR W23

DESTILLIERMEISTER JUNIOR-W23

23 l stainless steel still with pressurized water bath, 2 columns and high-performance cooling for the production of brandy

High Quality:

  • Solid thick-walled boiler for the water bath
  • with pressure measurement and safety valves,
  • made of 18/10 stainless steel with three-layered thermo bottom

Equipment and dimensions

  • Water bath boiler with safety system for the pressurized water bath: 16 liters

    The water bath system may only be operated in the fully closed state, that is, all the latches are closed.
  •  Mash-water boilers: 13,5 Litres,

  • 2 Columns / combustion-chamber extensions: 7 Litres,

  • Inner Diameter 28 cm,

  • Total height approx. 83 cm.

  • Powerful counterflow cooler with 1.6 m jacket length. In this cooler, a thinner pipe (core) passes through a jacket pipe. Through the soul flows the distillate. Between soul and coat cooling water is passed in countercurrent. Due to the spiral-shaped water flow, the flow between soul and mantle is turbulent even at low flow velocities. This causes effective heat transfer from the distillate to the cooling water. Because of this and because of the comfortable length of the radiator, only moderate cooling water is.

EUR 1.399,00
incl. 19% tax excl. Shipping costs
1 to 8 (from a total of 36)

Legal notice:

In Germany distilling plants and other equipment and articles intended for non-commercial extraction or purification of alcohol are prohibited. As a private person you are not allowed to purchase such devices in Germany.
Should no alcohol be produced or purified, eg. Hydrolates, essential oils, etc., you may also purchase and own devices as a private individual. Up to 2 liters of tank volume, these are not to report.
The only way in which you, as a private individual in Germany, are allowed to extract alcohol from distilled fruit products using certain conditions is to issue a burning permit for so-called substance owners.
